A Turning Cam course is associated with the design and production of camshafts, which are crucial components in engines. This course would likely delve into the engineering and manufacturing aspects of camshafts, including how to turn or machine them from raw materials. It could be relevant for automotive or mechanical engineering students and professionals
Description
What You'll Learn
Mould Design
Course Details
Course Level
Beginner
Duration
9 Months
Lectures
36 Lectures
Mode
Offline
COURSE NAME
2D Design ESSENTIALS
COURSE DURATION - 40 HRS
COURSE DESCRIPTION
In 2D Design essentials training course includes the most widely used commands and drawing techniques.
Getting trained in 2D Design essentials course means a lot for a beginner as his/her drafting passion will be viewed in a two dimensional CAD environment.
If, your ultimate goal is to touch the extremities in the design and drafting profession and a make it a career, We at Jagjit Institute will help you to understand the concept of Engineering Drawing and Machine Drawing and make you thoroughly capable of exploring the easy methods of creating complex drawings.
By following our professionally designed training technique, very quickly you will become well versed with creating all our basic level 2D (2 Dimensional) drawings in 2D Design.
You will be creating big assembly drawings and different parts in different layers and explore the use of line types, colors, line weights, dimensions and hatching patterns.
Creating blocks and attributes will help to insert objects repetitively without actually drawing them.
2D Design commands and drawing techniques taught are generic, relevant to all industries.
COURSE CONTENT
1. Introduction to 2D Design
Starting 2D Design software
Understanding the user interface
Interacting with 2D Design tools
2D Design File formats
2. Beginning By Creating First Drawing
Setting up a Drawing
Using 2D Design Drafting Tools
Understanding Objects
3. Understanding Viewing Options
Understanding the Display and Virtual Screen
Using ZOOM and PAN To Control the Display
Using the Aerial View Window and Creating Views
4. Accurate Drawing Techniques
Setting the Display Format and Units
Cartesian Coordinate System
Polar Coordinate System
5. Drawing Organisation
Working with Layers
Understanding and Creating Linetypes
Changing object properties
Matching object properties
6. Creating Basic Geometry
Drawing Rectangles
Drawing Circles
Drawing Arcs
7. Editing Drawings at Basic Level
Deleting and Restoring Objects
Moving, Copying, and Offsetting Objects
Rotating, Mirroring, Scaling, and Stretching Objects
Editing Edges and Corners of Objects
Producing Arrays of Objects
8. Annotate the Drawing
Creating Multiline text
Creating single line text
Using text styles
Editing Text
9. Dimensioning a Drawing
Dimensioning Basics and Dimensioning with Precision
Linear and Radial Dimensioning
Angular Dimensioning
Editing Dimensions
Using dimension styles
Using Multileaders
10. Hatching Objects
Hatching Objects
Editing hatch objects
11. Reusing Objects
Creating Blocks
Inserting Blocks
Using tool pallets
12. Printing and Plotting
Plot Settings
Plotting Drawings
PDF output
Using Plot styles
WHO SHOULD ATTEND
X, XII Pass Students
Graduates / Under Graduates
Interior Designers
Product Designers
Machine Operators
Maintenance Engineers
Production Engineers
OTHER RELEVANT COURSES
Freehand Sketching Fundamentals(EG1501)
Engineering Drawing Practices(EG1502)
Machine Drawing and Blueprint Reading(EG1503)
Construction Drawing Practices And Graphic Standards(EG1504)
Fundamentals Of Geometric Dimensioning & Tolerancing -GD&T(EG1505)
COURSE NAME
2D Design ESSENTIALS
COURSE DURATION - 40 HRS
COURSE DESCRIPTION
In 2D Design essentials training course includes the most widely used commands and drawing techniques.
Getting trained in 2D Design essentials course means a lot for a beginner as his/her drafting passion will be viewed in a two dimensional CAD environment.
If, your ultimate goal is to touch the extremities in the design and drafting profession and a make it a career, We at Jagjit Institute will help you to understand the concept of Engineering Drawing and Machine Drawing and make you thoroughly capable of exploring the easy methods of creating complex drawings.
By following our professionally designed training technique, very quickly you will become well versed with creating all our basic level 2D (2 Dimensional) drawings in 2D Design.
You will be creating big assembly drawings and different parts in different layers and explore the use of line types, colors, line weights, dimensions and hatching patterns.
Creating blocks and attributes will help to insert objects repetitively without actually drawing them.
2D Design commands and drawing techniques taught are generic, relevant to all industries.
COURSE CONTENT
1. Introduction to 2D Design
Starting 2D Design software
Understanding the user interface
Interacting with 2D Design tools
2D Design File formats
2. Beginning By Creating First Drawing
Setting up a Drawing
Using 2D Design Drafting Tools
Understanding Objects
3. Understanding Viewing Options
Understanding the Display and Virtual Screen
Using ZOOM and PAN To Control the Display
Using the Aerial View Window and Creating Views
4. Accurate Drawing Techniques
Setting the Display Format and Units
Cartesian Coordinate System
Polar Coordinate System
5. Drawing Organisation
Working with Layers
Understanding and Creating Linetypes
Changing object properties
Matching object properties
6. Creating Basic Geometry
Drawing Rectangles
Drawing Circles
Drawing Arcs
7. Editing Drawings at Basic Level
Deleting and Restoring Objects
Moving, Copying, and Offsetting Objects
Rotating, Mirroring, Scaling, and Stretching Objects
Editing Edges and Corners of Objects
Producing Arrays of Objects
8. Annotate the Drawing
Creating Multiline text
Creating single line text
Using text styles
Editing Text
9. Dimensioning a Drawing
Dimensioning Basics and Dimensioning with Precision
Linear and Radial Dimensioning
Angular Dimensioning
Editing Dimensions
Using dimension styles
Using Multileaders
10. Hatching Objects
Hatching Objects
Editing hatch objects
11. Reusing Objects
Creating Blocks
Inserting Blocks
Using tool pallets
12. Printing and Plotting
Plot Settings
Plotting Drawings
PDF output
Using Plot styles
WHO SHOULD ATTEND
X, XII Pass Students
Graduates / Under Graduates
Interior Designers
Product Designers
Machine Operators
Maintenance Engineers
Production Engineers
OTHER RELEVANT COURSES
Freehand Sketching Fundamentals(EG1501)
Engineering Drawing Practices(EG1502)
Machine Drawing and Blueprint Reading(EG1503)
Construction Drawing Practices And Graphic Standards(EG1504)
Fundamentals Of Geometric Dimensioning & Tolerancing -GD&T(EG1505)
COURSE NAME
2D Design 3D
COURSE DESCRIPTION
3D modeling is a professional approach towards transforming your design ideas into solid models
With 2D Design 3D you can explore one of the most exciting areas of CADD (Computer Aided Design and Drafting).
All the drawings are created in 3 dimensions wherein you can set the display of the model in wireframe or solid etc. along with viewing from different directions by rotating the object using 3D rotation, zooming, panning and 3D scaling.
You can perform the sectioning of solid objects by selecting various plane locations.
This job oriented course is purely designed by our expert team to meet the knowledge required by industrial design professionals in the field of Architectural, Mechanical, Interior Designing and Civil etc.
The course is well designed to understand the concepts for creating 3D assembly and plotting the individual components of the assembly by creating different general views from the 3D models.
COURSE DURATION - 5 DAYS
COURSE CO-ORDINATORS
Our 2D Design trainers are Autodesk Certified Instructors. They have vast experience of using 2D Design in industry.
COURSE TOPICS
1. Basics of 3D CAD
Advantages of Drawing in Three Dimensions
Viewing a 3D Model
Rotating the View
Additional Shading Modes
Adding Thickness to 2D Objects
Setting the Elevation
Displaying More Than One View of a Model
2. Working with 3D Coordinate System
Understanding 3D Coordinate Systems
3D Object Snaps
Point Filters
The User Coordinate System
The UCS View Option
UCS 3point
Working with Multiple UCSs
3. Solid Modeling
Wireframe Models
Surface Models
Solid Models
Solid Modeling Definitions and Concepts
Creating Solid Models from Two Dimensional Shapes
Extruding 2D Geometry
Creating Solid Models with Solid Primitives
Revolved Solids
Controlling the Appearance of Solids
4. Creating Composite Solid Models
Concept of composite solid model
Boolean Operations
Adding Solid Objects
Subtracting Solid Objects
Intersecting Solid Objects
5. Modifying Solid Models
Filleting Solid Models
Chamfering Solids
Generating Mass Property Reports
Slicing a Solid along a Plane
Cross-Sectional Views
Moving Faces
Tapering Faces
Deleting Faces and Creating a Shell
Advanced Solid Editing Options
6. 3D Concepts : Advance Level
The coordinate system
Advanced UCS Concepts
Rotating the UCS
Saving and Restoring a UCS
Named Views in 3D
Printing/Plotting 3D Models
7. Working with the Layout Feature and Layout Tabs
Layouts: A New Look for Plotting
Changing from Model Mode to Layout Mode
Creating a New Layout
Specifying Page Setup
Specifying a Plot Device
Layout Settings
8. Working With The Viewports Dialog Box
Scaling Viewports
Copying an Existing Layout
Non-rectangular Viewports
Floating Viewports Setup
Creating 2D Views from a Solid Model
Creating Profiles from Solids
WHO SHOULD ATTEND
2D Design users
X, XII Pass
Graduates / Under Graduates
ITI / Diploma /B.E / B.Tech. / B. Arch
Interior Designers
Product Designers
Machine Operators
Maintenance Engineers
Production Engineers
PREREQUISITES - None
ALLIED COURSES
2D Design Essentials (Course Code : ACAD1501)
2D Design Advanced (Course Code : ACAD1502)
Freehand Sketching Fundamentals (Course Code : EG1501)
Engineering Drawing Practices (Course Code : EG1502)
Machine Drawing and Blueprint Reading(Course Code : EG1503)
Construction Drawing Practices And Graphic Standards (Course Code : EG1504)
Fundamentals Of Geometric Dimensioning & Tolerancing -GD&T (Course Code : EG1505)
